Part No: RK-LG-20-MEN-C120-750-YM-415
Replaces: 750W+ HID
200W LED Retro Unit – 29,466 Lumens
Description
| SPECIFICATIONS | |||||||
|---|---|---|---|---|---|---|---|
| Type | LED Retro Kits | ||||||
| Wattage | 200W | ||||||
| CRI | 75+ | ||||||
| Lumens | 29,466 | ||||||
| Lumen Per Watt | 147 | ||||||
| Color Temperature | 4100K | 4500K | 5000K | 5500K | ||||||
| Beam Angle | deg | ||||||
| Optics | 120 deg Standard | 60 deg Special Order | ||||||
| Life Hours | 100,000 | ||||||
| Replaces | up to 750W+ HID | ||||||
| Working Voltage | 100-277 | 347-480 VAC | ||||||
| Frequency | 50/60 hz | ||||||
| Operating Temperature | -30 degC to +45 degC | ||||||
| Dimmable | No | ||||||
| Dimensions | 8.6′ L x 5.7′ W x 1.4′ H | ||||||
| Net Weight | .77kg | ||||||
| Housing | IP65 | ||||||
| Mounting | Yoke or flex fixture bracket mount | ||||||
| Warranty | 5 years on driver, 10 years on head | ||||||
| Model | Wattage | Replaces HID | Lumens |
|---|---|---|---|
| RK-LG-20-MEN-C120-750-YM-415 | 200W | 750W+ | 29,466 |
Features:
- This 200 Watt LED Retro unit wins in life rating, wattage savings, payback, CRI, and the ability to retrofit in 99% of existing HID fixtures.
- IP65 for outdoor use
- L70 of 70,000+ hours long life low maintenance
- The ability to retrofit in to almost any HID fixture up to 750 Watts HID
- Over temperature protection
- Short Circuit / Over Current / Over Voltage / Over Temperature Protection With Auto Recovery
Options:
- fixture mounting bracket (Flex)
- dimmable driver
- turtle safe amber 590 nM (special order)
